SCHNEIDER
undervoltage release (pre-wired) MN - 208...240 V AC 60Hz - 220…240 V 50Hz - LV426824
LV426824
This product is no longer available. Contact us for a suitable replacement solution tailored to your needs.
Technical informations
| Range: | ComPact |
|---|---|
| Range of product: | ComPacT NSXm new generation |
| Device short name: | MN |
| Product or component type: | Voltage release |
| Device application: | Control |
| Range compatibility: | ComPacT NSXm new generationComPact NSXmPowerPact B |
| Voltage release type: | Opening coilUndervoltage release |
| [Uc] control circuit voltage: | 220...240 V AC 50 Hz208...240 V AC 60 Hz |
| Threshold tripping voltage: | 0.35...0.7 x Un opening0.85 x Un closing |
|---|---|
| Response time: | |
| Auxiliary connection terminal: | Pre-wired 0...0.8 mm² (AWG 18)stranded copper |
| Wire stripping length: | 8 mm |
| Length: | 1 m |
In short
Reference LV426824
Product Name undervoltage release (pre-wired) MN - 208...240 V AC 60Hz - 220…240 V 50Hz - LV426824
