SCHNEIDER
trip unit MA150 for ComPacT NSX 160/250 circuit breakers, magnetic, rating 150 A, 4 poles 4d - C166MA150
C166MA150
€143.14 Excl. Tax
€171.77 Inc. Tax
Excl. Tax
Excl. Tax
Incl. Tax
Incl. Tax
You save
Supply in process - Average delivery time 4/6 weeks
- Technical support and dedicated single point of contact
- Free delivery from 250€ of purchase (Metropolitan France)
- 100% secure payments
Technical informations
| Range: | ComPacT new generation |
|---|---|
| Range of product: | ComPacT NSX100...250 new generation |
| Product or component type: | Trip unit |
| Trip unit name: | MA |
| Trip unit technology: | Magnetic |
| Range compatibility: | ComPacT new generation NSX160ComPacT new generation NSX250 |
| Device application: | Motor |
| Poles description: | 4P |
| Protected poles description: | 3D |
| Neutral position: | Left |
| Trip unit protection functions: | I |
| Protection type: | I |
| [In] rated current: | 150 A at 65 °C |
| [Ue] rated operational voltage: | 690 V AC 50/60 Hz |
| Network type: | AC |
| Network frequency: | 50/60 Hz |
| Mounting mode: | Fixed |
| Neutral protection setting: | No protection (3D) |
|---|---|
| Instantaneous pick-up adjustment type Ii: | Adjustable |
| Instantaneous pick-up adjustment range: | 9...14 x In |
| Earth-leakage protection: | Without |
In short
Reference C166MA150
Product Name trip unit MA150 for ComPacT NSX 160/250 circuit breakers, magnetic, rating 150 A, 4 poles 4d - C166MA150
Range ComPacT nouvelle génération
