SCHNEIDER
TeSys GV3L magnetic motor circuit breaker 80A EverLink - GV3L80
GV3L80
€141.04 Excl. Tax
€169.25 Inc. Tax
Excl. Tax
Excl. Tax
Incl. Tax
Incl. Tax
You save
In stock – Dispatched within 24/48h
- Technical support and dedicated single point of contact
- Free delivery from 250€ of purchase (Metropolitan France)
- 100% secure payments
Technical informations
| Range: | TeSys Deca |
|---|---|
| Range of product: | TeSys GV3TeSys Deca |
| Product name: | TeSys GV3TeSys Deca |
| Product or component type: | Motor circuit breaker |
| Device short name: | GV3L |
| Device application: | Motor protection |
| Trip unit technology: | Magnetic |
| Poles description: | 3P |
|---|---|
| Network type: | AC |
| Utilisation category: | Category A conforming to IEC 60947-2 |
| Network frequency: | 50/60 Hz |
| Fixing mode: | 35 mm symmetrical DIN rail: clippedPanel: screwed (with 3 x M4 screws) |
| Motor power kW: | 45 kW at 400/415 V AC 50/60 Hz maximum peak current 750 A55 kW at 690 V AC 50/60 Hz maximum peak current 750 A45 kW at 500 V AC 50/60 Hz maximum peak current 750 A |
| Breaking capacity: | 50 kA Icu at 440 V AC 50/60 Hz12 kA Icu at 500 V AC 50/60 Hz6 kA Icu at 690 V AC 50/60 Hz50 kA Icu at 400/415 V AC 50/60 Hz65 kA Icu at 230/240 V AC 50/60 Hz |
| [Ics] rated service short-circuit breaking capacity: | 100 % at 230/240 V AC 50/60 Hz50 % at 500 V AC 50/60 Hz50 % at 690 V AC 50/60 Hz60 % at 400/415 V AC 50/60 Hz60 % at 440 V AC 50/60 Hz |
| Control type: | Rotary handle |
| [In] rated current: | 80 A |
| Magnetic tripping current: | 1120 A |
| [Ue] rated operational voltage: | 690 V AC 50/60 Hz conforming to IEC 60947-2 |
| [Ui] rated insulation voltage: | 690 V AC 50/60 Hz conforming to IEC 60947-2 |
| [Uimp] rated impulse withstand voltage: | 6 kV conforming to IEC 60947-2 |
| Suitability for isolation: | Yes conforming to IEC 60947-1 |
| Power dissipation per pole: | 8 W |
| Mechanical durability: | 50000 cycles |
| Electrical durability: | 20000 cycles for AC-3 at 415 V In |
| Maximum operating rate: | 25 cyc/h |
| Direct connector: | Without |
| Tightening torque: | 5 N.m - on screw clamp terminal |
| Width: | 55 mm |
| Height: | 132 mm |
| Depth: | 136 mm |
| Net weight: | 0.96 kg |
| Colour: | Dark grey |
| Compatibility code: | GV3L |
In short
Reference GV3L80
Product Name TeSys GV3L magnetic motor circuit breaker 80A EverLink - GV3L80
Range TeSys Deca
