Plug panel, Mureva PK, 16A, 3P+N+E, 400V, IP67 - 83859

Name: Plug panel, Mureva PK, 16A, 3P+N+E, 400V, IP67 - 83859
Brand: Mureva
SKU: 83859
Price: 24.77 EUR
Availability: InStock

83859

€20.64 Excl. Tax

€24.77 Inc. Tax

In stock – Dispatched within 24/48h

Technical informations

Mounting mode:	Panel-mounted
Plug, socket, control station shape:	90° angled
[In] rated current:	16 A
[Ue] rated operational voltage:	380...415 V
Network frequency:	50/60 Hz
Ground lug clockwise position:	6 h
Plug, socket material:	Self-extinguishing engineering polymer
Contacts material:	Pins: nickel plated brass
Connections - terminals:	Captive screws
Cable cross section:	1...4 mm²
Net weight:	0.256 kg
Base dimension:	90 x 100 mm
Height:	148 mm
Width:	90 mm
Depth:	107 mm
Colour:	Grey (RAL 7035)
Voltage colour:	Red
Market segment:	Small commercial
Compatibility code:	Mureva plug

Standards:	EN 60309-2EN 60309-1
IP degree of protection:	IP67 conforming to IEC 60529
IK degree of protection:	IK08 conforming to EN 62262
Fire resistance:	850 °C conforming to IEC 60695-2-1
Relative humidity:	50 % at 40 °C70 % at 30 °C90 % at 20 °C
Operating altitude:	2000 m
Ambient air temperature for operation:	35 °C ( 86400 s ) -25...40 °C
Total lifecycle Carbon footprint:	12 kg CO2 eq.Carbon footprint of the manufacturing phase [A1 to A3]
Unit Type of Package 1:	PCENumber of Units in Package 1

In short

Reference 83859

Product Name Plug panel, Mureva PK, 16A, 3P+N+E, 400V, IP67 - 83859

Range Mureva
